How to Select the Proper Sargent 351 Door Closer

commercial-door-hardware















Featuring heavy-duty construction for superior strength and wear resistance, the Sargent 351 Series Powerglide® Door Closer is ideally suited for highly trafficked environments like schools, healthcare facilities, and office and commercial buildings. With a full complement of arm types and front-facing valves, the 351 series can be easily installed and maintained—for interior and exterior applications.

Things to Consider

1. Size and Weight of Door

The 351 Door Closers is non-sized so that closing force can be adjusted in the field to accommodate various door sizes and weights.

2. Interior Application

The standard application is the most efficient in terms of power and control.

3. Exterior Application

The top jamb, corner bracket or parallel arm application should be used. Exterior doors require greater closing forces because of draft conditions. Always place the closers out of the weather.

4. Degree of Opening

Proper arm and position on the door is most
important to permit the door to open far
enough to allow adequate traffic flow.

5. Function

Closers are available with hold-open or positive stop arms.

6. Special Condition

Consult factory when special hinges, overhead holders or other specialized hardware is used.

commercial-door-hardware











































commercial-door-hardware



















































Qualitydoor.com is the trusted source for all of your Sargent Door Hardware needs. We have a large inventory of Sargent Panic/Exits Devices that ship within 24 hrs to one week of order placement.

Established in 1988, QualityDoor.com is Veteran Owned and Operated as well as holding two GSA Contracts on schedules 84 and 56.

Call 800.992.3667 or email us at Sales@qualitydoor.com.

Choosing a Rixson Floor Closer

Rixson Floor closers provide the best mechanical means to support and control a door. They are designed to work with the laws of physics to provide long-lasting performance and reliability. The weight of the door is supported by a bottom arm and floor which allows the door to swing with less resistance, and as a result, heavier doors can be accommodated with reduced stress on frame.

Model 27

commercial-door-hardwareRixson Model 27 is 3/4″ offset hung single acting floor closer for exterior or interior doors.

They are made to support weight up to 450 lbs and door width up to 4’0″ (1219mm).



Model 28

commercial-door-hardware

Rixson Model 28 is a single acting center hung floor closer for exterior or interior doors that weigh up to 350 lbs.

It has a centering arm for sizes up to 4’0″ x 8’6″* (1219 x 2591mm)



Model 30

commercial-door-hardwareThe Rixson Model 30 is a double-acting center hung floor closer for interior and exterior doors that weight to 200 lbs.

It has a centering arm for sizes up to 4’0″ x 8’6″* (1219 x 2591mm).

Model 40

commercial-door-hardwareRixson Model 40 is a double acting, center hung floor closer for exterior or interior doors that weigh up to 300 lbs.

The centering arm is for door sizes up to 4’0″ x 8’6″* (1219 x 2591mm).

Model L 127

commercial-door-hardwareRixson Model L 127 is a 3/4″ offset single acting floor closer designed for exterior or interior doors.

It is recommended for deep reveal applications for doors that weigh up to 250lbs and have widths up to 4’0″ (1219mm).



Qualitydoor.com is the trusted source for all of your Rixson Pivots needs. We have a large inventory that ships within 24 hrs to one week of order placement.

Established in 1988, QualityDoor.com is Veteran Owned and Operated as well as holding two GSA Contracts on schedules 84 and 56.

Call 800.992.3667 or email us at Sales@qualitydoor.com.



Choosing a Rixson Pivot

Rixson Pivot sets provide the best possible means of hanging a door. They are designed to work with the laws of physics to provide long-lasting performance and reliability. Offset, Top , Intermediate, Electric, Center Hung, and Pocket Pivots: What are these and what do they do?

Offset Pivots

rixson-pivots

Offset pivots provide better weight distribution and can accommodate taller doors. A 3/4″ Offset is when a pivot point is located 3/4″ from the heel edge of the door and 3/4″ from face of door. While a 1-1/2″Offset is when a pivot point located 3/4″ from the heel edge of the door and 1-1/2″ from face of door. Extended offsets should be used when there is cladding on the face of door or trim on the frame. Offset Pivots Include, 117, 117 1/4. 147, L147, and the 195.

Top Pivots

Rixson-Pivots-Commercial-Door-Hardware

Top Pivots are used to ensure proper installation and alignment at the top of the door. Rixson 180 is the standard full mortise top pivot for most offset pivot sets and floor closers (Also comes in H180 for Heavy Duty). The L180 is the standard top pivot for L147, L117 pivots and L27 floor closers. The 380 is for flush door and frame application only.

Intermediate Pivots

commercial-door-hardwareIntermediate Pivots are used for alignment and to ensure proper installation of bottom pivot or floor closer. The Rixson m19 is Full Mortise, not load-bearing, and maintains door alignment. The M190 is used when frame condition does not allow standard top pivot. And the Ml19 Screw holes spaced to straddle lead lining in center of door and is also used on extra heavy or high traffic door.

Electrified Pivots

commercial-door-hardware

Electrified Pivots are used for power transfer and/or door position monitoring.

The E-M19-4 and the E-m19U are recommended for these applications.

Center Hung

commercial-door-hardware

Center Hung Pivots are used for aesthetics or if the pivot point is going to be moved closer to the lock edge of the door. The Rixson 127-3/4 works well for interior doors that weigh to 200 lbs. The 128-3/4 is identical to the 127-3/4 except the bottom pivot mounts directly to floor. While the 370 is for interior and exterior doors weighing up to 500 lbs.

Pocket Pivots

commercial-door-hardwareThe Rixson F519 is a full mortise, non-handed pivot for pocket door applications.

It allows allows doors to swing 90°.
